Features:

1.        This CNC pipe bender is a multi-axes servo drive and IPC system equipment with high intelligence and automation, it can be processed by stretch bending or stretch bending plus pushing bending.

2.        This machine can install bending dies of different radius in one time, the multiple radius processing for one pipe can be realized.

3.        All the data can be input by the touch screen, the transport software provides direct data transfer function by serial ports, and transfer to IPC through server. The data can be adjusted by the server and IPC, then judge the bending parameters.

4.        The fault analysis will be done by the long distance desktop service.

5.        The pipe bender control system have the perfect interfere inspect and self-protecting functions, before running the programs, a safety inspect will be advanced according to the die parameters and processing parameters which had been entered, the alarm message will show the operator if the interfere inspect happened.

6.        The range of the interfere inspect include machine body part, dies, the interference between ground and tubes.

7.        This machine can bend with or without mandrel.

8.        The bending data can be input directly to coordinate(X, Y, Z) or working data(Y, B, C). It is possible to transfer between coordinate and working data, also can calculate the feeding length precisely.

9.        With program mirroring self editing.

10.     The storage of Max. bending programs and data are unlimited .

11.     The program memory function can memorize the files permanently during sudden power off.

12.     12. When editing the bending programs, some bends can be add or delete freely, and the editing programs can be memorized as a renamed program.

13.     13. The manual, semi-auto and automatic operation can be set.

14.     The feeding style includes clamp feeding and direct feeding.
